Roller Diameter

:

Max 800 mm

Reel Weight

:

Max 400 kg

Roller Width

:

375-660 mm

Line Speed

:

Max. 200 m / min

Operation and Shutdown Time

:

20 seconds

Sudden Stop Time

:

6 seconds

Drive Motor Type

:

AC Servo

Drive Motor Power

:

0.75 kW

Mains Voltage

:

400 V; 50 Hz

Roller Diameter

:

Min 500-Max 800 mm

Transfer Speed

:

Max 300 m / min

Roller Width

:

600 mm

Weight of the Spool

:

Max 400 kg

Traverse Step (For Winder)

:

0,5 mm - 10 mm

Main Drive Motor Type

:

 AC Servo

Main Drive Motor Power

:

1.5 kW / 2.04 hp

Max Torque

:

21.5 nm

Max Rotation Speed

:

 2000 rpm

Reel Loading and Unloading Speed

:

10 sec

Machine Direction

:

Left to Right (optional)

Number of Cores

:

18 + 1

Centering Disc Diameter

:

66 mm

Turning Discs Diameter

:

43 mm

Pitch Length

:

30-1000 mm

Machine Length

:

5 meters

Rotation speed

:

2000 rpm

Rotating Head Max. Speed of Rotation

:

900 rpm

Flange Diameter of the Spool

:

600 - 1200 mm

Roller Width

:

300 - 1000 mm

Weight of the Spool

:

Max 500 kg

Traverse Pitch

:

3 mm - 30 mm

Winding Speed

:

10 m - 200 m

Main Drive Motor Type

:

AC Servo

Max Torque

:

21.5 nm

Max Rotation Speed

:

2000 rpm

Reel Lower Lifting Speed

:

10 sec
